Friedrich UCT10B30A Uni-Fit Series 10000 BTU Smart WiFi Through-the-Wall Air Conditioner - 230 Volt - R32 Refrigerant

Sku:
FRIEDRICH-UCT10B30A
Usually Leaves Warehouse in 5 - 7 Business Days
$799.00
Uni-Fit Series air conditioners offer a Universal Fit for replacing most older units using their existing sleeves without complicated, time-consuming retrofits. The Uni-Fit Series' characteristically small dimensions are specifically designed to replace virtually any thru-the-wall air conditioner, while the solid-side sleeve makes the Uni-Fit model ideal for installation through thicker walls without compromising the performance of the unit.

The Uni-Fit UCT10B30A unit uses R32 refrigerant with low Global Warming Potential (GWP)! R32 refrigerant is more efficient than R410A which results in the lower GWP.

In addition to having built-in WiFi, other features of the UCT10B30A Uni-Fit include 10,000 BTU cooling capacity in a thru the wall installation, smart home/ voice command compatibility, auto restart, washable filter, 8 way air flow control, a 24 hr. timer and a Money Saver® setting. Download the FriedrichGo App and you will have control over your Uni-fit at home or away. It is also compatible with Google Home and Alexa.

The chassis is designed to fit 24-1/2”, 26" or 27” sleeves. The unit includes a universal fit decorative trim ring to close the gap if using a competitor sleeve. New installations require a sleeve. The Friedrich USC sleeve (sold separately) fits standard 26” sleeve opening. It also includes all accessories required for installation - inner and outer weather panels and a standard grille. The USC sleeve is 15-1/2"h x 25-7/8"w x 16-3/4"d.

This model meets the requirements for use in California and Washington.

FREE SHIPPING ON ALL ORDERS!
Friedrich UCT10B30A Uni-Fit Series 10000 BTU Smart WiFi Through-the-Wall Air Conditioner - 230 Volt - R32 Refrigerant
  • Friedrich UCT10B30A Uni-Fit Series 10000 BTU Smart WiFi Through-the-Wall Air Conditioner - 230 Volt - R32 Refrigerant
  • Friedrich UCT10B30A Uni-Fit Series 10000 BTU Smart WiFi Through-the-Wall Air Conditioner - 230 Volt - R32 Refrigerant
Product Videos

Product Overview

Uni-Fit Series air conditioners offer a Universal Fit for replacing most older units using their existing sleeves without complicated, time-consuming retrofits. The Uni-Fit Series' characteristically small dimensions are specifically designed to replace virtually any thru-the-wall air conditioner, while the solid-side sleeve makes the Uni-Fit model ideal for installation through thicker walls without compromising the performance of the unit.

The Uni-Fit UCT10B30A unit uses R32 refrigerant with low Global Warming Potential (GWP)! R32 refrigerant is more efficient than R410A which results in the lower GWP.

In addition to having built-in WiFi, other features of the UCT10B30A Uni-Fit include 10,000 BTU cooling capacity in a thru the wall installation, smart home/ voice command compatibility, auto restart, washable filter, 8 way air flow control, a 24 hr. timer and a Money Saver® setting. Download the FriedrichGo App and you will have control over your Uni-fit at home or away. It is also compatible with Google Home and Alexa.

The chassis is designed to fit 24-1/2”, 26" or 27” sleeves. The unit includes a universal fit decorative trim ring to close the gap if using a competitor sleeve. New installations require a sleeve. The Friedrich USC sleeve (sold separately) fits standard 26” sleeve opening. It also includes all accessories required for installation - inner and outer weather panels and a standard grille. The USC sleeve is 15-1/2"h x 25-7/8"w x 16-3/4"d.

This model meets the requirements for use in California and Washington.


Tech Specs

General Features

Type of Through-the-Wall:
26" Through-the-Wall
Sleeve Required for Install:
Yes
Fits Sleeve Size (in.):
26
Refrigerant Type:
R32
Compressor:
Standard
Energy Star:
No
Dehumidification (pts/hr):
1.25
CFMs:
265
Includes Heat Mode:
No

Performance @230 Volt

Cooling BTUs (@230V):
10000
EER (@230V):
10.7
CEER (@230V):
10.6
Cooling Amps (@230 Volt):
4.5
Cooling Watts (@230 Volt):
940

Features

Vent Location:
Front Top
Make-Up Air:
No
Energy Saver Mode:
Yes
Fan Speeds:
3
Control Type:
Electronic/Digital
Filter Access:
Front Lift Out
Connectivity:
Built-In WiFi
24 Hour ON/OFF Timer:
Yes
Remote Control:
Yes
Fresh Air Intake:
No
Sleep Mode:
No

Weights and Dimensions

Width (in.):
24.25
Depth (in.):
20.313
Height (in.):
14.5
Max. Wall Thickness (in.):
16.25
Wall Cut-Out Width (in.):
26.125
Wall Cut-Out Height (in.):
15.75
Extension Into Room (Min)(in.):
3.75
Weight (lbs.):
74
Certifications:
AHAM, UL, CUL

Electrical Requirements

Voltage:
208-230V
Plug Face (NEMA):
6-20P
Circuit Breaker Size (Amps):
20
Cord Length:
6'
California residents see Prop 65 WARNINGS

Warning WARNING!

Warning: Cancer and Reproductive Harm - www.p65warnings.ca.gov

Product Warranty

Parts and Labor: One year limited; Sealed Refrigeration System: 5 Year Limited
